Effects of Lower Limb Robot Combined with Motor Therapy on Exercise Endurance，Cognitive Function and Limb Function in Stroke Patients with Spastic Hemiplegia
-
摘要:
目的 探究下肢机器人联合运动疗法对脑卒中下肢痉挛性瘫痪患者运动耐力、认知功能及肢体功能的影响。 方法 选择2023年1月至2025年1月首都医科大学附属北京康复医院收治的脑卒中下肢痉挛性瘫痪患者110例，随机数字表法分为常规组和联合组，各55例。常规组采用常规康复治疗，联合组在常规康复治疗的基础上，将部分运动疗法替换为下肢机器人辅助训练联合运动疗法。采用6分钟步行试验（6-minute walk test，6MWT）评估患者运动耐力变化；通过心肺运动试验测定峰值摄氧量（peak oxygen uptake，VO2peak）与无氧阈值（anaerobic threshold，AT）；改良Ashworth量表（modified ashworth scale，MAS）评估患者下肢肌肉痉挛程度；Berg平衡量表（berg balance scale，BBS）评估患者平衡能力；Fugl-Meyer评估量表（fugl-meyer assessment scale，FMA）评估患者运动功能；卒中量表（national institutes of health stroke scale，NIHSS）评估患者神经功能缺损程度；认知评估量表（montreal cognitive assessment，MoCA）评估患者认知功能；Barthel指数（nodified barthel index，MBI）评估患者日常生活能力；自制满意度调查问卷评估患者对治疗过程及效果的主观感受。 结果 治疗后，联合组6MWT、VO2peak及AT均高于常规组（P < 0.05）；联合组MAS改善程度高于常规组（P < 0.05）；联合组BBS、FMA高于常规组（P < 0.05）；联合组NIHSS低于常规组，MoCA高于常规组（P < 0.05）；联合组MBI高于常规组（P < 0.05）；联合组患者满意度高于常规组（P < 0.05）。 结论 下肢机器人联合运动疗法可有效改善脑卒中下肢痉挛性瘫痪患者运动耐力、认知功能及肢体功能。 Abstract:Objective To explore the effects of lower limb robot-assisted training combined with exercise therapy on the exercise endurance, cognitive function and limb function in stroke patients with spastic hemiplegia. Methods A total of 110 stroke patients with spastic paralysis of the lower extremities admitted to Beijing Rehabilitation Hospital Affiliated to Capital Medical University from January 2023 to January 2025 were selected and divided into a conventional group （n = 55） and a combined group （n = 55） by the random number table method. The conventional group received conventional rehabilitation treatment, while the combined group received a modified regimen on the basis of conventional rehabilitation treatment, where part of the exercise therapy was replaced by lower limb robot-assisted training combined with exercise therapy. The 6-Minute Walk Test （6MWT） was used to evaluate the changes in patients' exercise endurance. Peak Oxygen Uptake （VO2peak） and Anaerobic Threshold （Anaerobic threshold, AT） were determined by cardiopulmonary exercise test; The Modified Ashworth Scale （MAS） was used to evaluate the degree of lower extremity muscle spasm in patients. The Berg Balance Scale （BBS） was used to assess the balance ability of patients. The Fugl-Meyer Assessment Scale （FMA） was used to evaluate the motor function of patients. Neurological deficit severity was measured with the National Institutes of Health Stroke Scale （NIHSS）.The Montreal Cognitive Assessment （MoCA） was used to evaluate the cognitive function of patients. Activities of daily living were evaluated using the Modified Barthel Index （MBI）. The Modified Barthel Index （MBI） assesses the daily living ability of patients. A self-made satisfaction questionnaire was used to evaluate patients' subjective feelings about the treatment process and effect. Results After treatment, the Combined Group showed significantly higher values in 6MWT, VO2peak and AT compared to the conventional group （P < 0.05）; the improvement in MAS in the combined group was greater than that in the conventional group （P < 0.05）; both BBS and FMA scores were significantly elevated in the combined group relative to the conventional group （P < 0.05）; the NIHSS scores in the combined group were lower than that in the conventional group, and the MoCA scores were higher than that in the conventional group （P < 0.05）; the MBI in the combined group was higher than that in the conventional group （P < 0.05）; The satisfaction rate of patients in the combined group was higher than that in the conventional group （P < 0.05）. Conclusion Lower limb robot-assisted training combined with exercise therapy can effectively improve the exercise endurance, cognitive function and limb function of patients with spastic hemiplegia after stroke. -
表 1 一般资料[（$ \bar x \pm s $）/n（%）]
Table 1. General information[（$ \bar x \pm s $）/n（%）]
组别 n 性别 年龄（岁） 病程（d） 卒中类型 偏瘫侧 男 女 缺血性 出血性 左脑 右脑 常规组 55 30（54.55） 25（45.45） 61.65 ± 10.38 28.59 ± 5.93 38（69.09） 17（30.91） 29（52.73） 26（47.27） 联合组 55 32（58.18） 23（41.82） 62.27 ± 10.31 29.64 ± 6.01 35（63.64） 20（36.36） 24（43.64） 31（56.36） χ2t 0.148 0.314 0.922 0.367 0.910 P 0.701 0.754 0.358 0.545 0.340 组别 n 6MWT（m） BBS（分） FMA（分） NIHSS（分） MoCA（分） 常规组 55 92.54 ± 16.94 28.32 ± 4.56 16.23 ± 3.21 22.29 ± 3.61 14.62 ± 2.97 联合组 55 91.86 ± 16.73 27.98 ± 4.17 16.01 ± 3.15 21.86 ± 3.57 14.47 ± 2.84 χ2t 0.212 0.408 0.363 0.628 0.271 P 0.833 0.684 0.717 0.531 0.787
下载: 导出CSV
表 2 两组患者治疗前后6MWT、VO2peak及AT比较（$ \bar x \pm s $）
Table 2. Comparison of 6MWT，VO2peak，and AT between the two groups before and after treatment（$ \bar x \pm s $）
组别 6MWT（m） t P VO2peak[mL/（kg·min）] t P AT[mL/（kg·min）] t P 治疗前 治疗后 治疗前 治疗后 治疗前 治疗后 常规组
（n=55）92.54 ± 16.94 182.74 ± 35.67 16.940 <0.001*** 15.68 ± 1.34 17.42 ± 1.19 7.201 <0.001*** 12.35 ± 1.89 13.57 ± 2.05 3.245 0.002** 联合组
（n=55）91.86 ± 16.73 214.52 ± 40.17 20.670 <0.001*** 15.41 ± 1.20 20.27 ± 1.53 18.540 <0.001*** 12.12 ± 1.74 14.41 ± 2.18 6.089 <0.001*** t 0.212 4.354 1.113 10.900 0.664 2.082 P/校正
后P值0.833 0.001**/0.003* 0.268 <0.001***/0.001*** 0.508 0.040*/0.120 *P < 0.05；**P < 0.01；***P < 0.001。
下载: 导出CSV
表 3 两组患者MAS比较[n（%）]
Table 3. Comparison of MAS between the two groups[n（%）]
组别 时间 0级 1级 1+级 2级 3级 Z P/校正后P值 常规组（n=55） 治疗前 0（0.00） 6（10.91） 11（20.00） 22（40.00） 16（29.09） 0.369 0.952 联合组（n=55） 0（0.00） 5（9.09） 13（23.64） 20（36.36） 17（30.91） 常规组（n=55） 治疗后 3（5.45） 13（23.64） 11（20.00） 18（32.73） 10（18.18） - 0.040*/0.080 联合组（n=55） 9（16.36） 18（32.73） 15（27.27） 9（16.36） 4（7.27） 常规组（n=55） 治疗前 0（0.00） 6（10.91） 11（20.00） 22（40.00） 16（29.09） 7.154 0.197 治疗后 3（5.45） 13（23.64） 11（20.00） 18（32.73） 10（18.18） 联合组（n=55） 治疗前 0（0.00） 5（9.09） 13（23.64） 20（36.36） 17（30.91） - 0.003***/0.006** 治疗后 9（16.36） 18（32.73） 15（27.27） 9（16.36） 4（7.27） *P < 0.05；***P < 0.001。
下载: 导出CSV
表 4 两组患者BBS、FMA比较（$ \bar x \pm s $）
Table 4. Comparison of BBS and FMA scores between the two groups（$ \bar x \pm s $）
组别 BBS t P FMA t P 治疗前 治疗后 治疗前 治疗后 常规组（n=55） 28.32 ± 4.56 35.21 ± 5.43 7.206 <0.001*** 16.23 ± 3.21 25.15 ± 3.89 13.120 <0.001*** 联合组（n=55） 27.98 ± 4.17 38.27 ± 5.84 10.630 <0.001*** 16.01 ± 3.15 28.76 ± 4.23 17.930 <0.001*** t 0.408 2.846 0.363 4.659 P/校正后P值 0.684 0.005**/0.010* 0.717 0.001**/0.002** **P < 0.01；***P < 0.001。
下载: 导出CSV
表 5 两组患者NIHSS、MoCA比较（$ \bar x \pm s $）
Table 5. Comparison of NIHSS and MoCA scores between the two groups（$ \bar x \pm s $）
组别 NIHSS t P MoCA t P 治疗前 治疗后 治疗前 治疗后 常规组（n=55） 22.29 ± 3.61 14.37 ± 1.91 14.380 <0.001*** 14.62 ± 2.97 18.59 ± 3.94 5.967 <0.001*** 联合组（n=55） 21.86 ± 3.57 10.41 ± 1.84 21.140 <0.001*** 14.47 ± 2.84 21.18 ± 4.14 9.912 <0.001*** t 0.628 11.070 0.271 3.361 P/校正后P值 0.531 <0.001***/0.001*** 0.787 0.001**/0.002** **P < 0.01；***P < 0.001。
下载: 导出CSV
表 6 两组患者MBI及满意度比较（$ \bar x \pm s $）
Table 6. Comparison of MBI and satisfaction scores between the two groups（$ \bar x \pm s $）
组别 MBI t P 满意度 治疗前 治疗后 常规组（n=55） 53.31 ± 10.26 68.75 ± 12.52 7.074 <0.001*** 21.23 ± 3.72 联合组（n=55） 52.84 ± 10.11 76.51 ± 13.17 10.570 <0.001*** 24.62 ± 4.11 t 0.242 3.167 4.535 P/校正后P值 0.809 0.002**/0.004** <0.001***/ < 0.001*** **P < 0.01；***P < 0.001。
下载: 导出CSV
-
[1] Potter T B H, Tannous J, Vahidy F S. A contemporary review of epidemiology, risk factors, etiology, and outcomes of premature stroke[J]. Curr Atheroscler Rep, 2022, 24(12): 939-948. [2] Lee S Y, Jeon Y T, Kim B R, et al. Combined treatment of botulinumtoxin and robot-assisted rehabilitation therapy on poststroke, upper limb spasticity: A case report[J]. Medicine (Baltimore), 2017, 96(51): e9468. [3] Mizuta N, Hasui N, Kai T, et al. Characteristics of limb kinematics in the gait disorders of post-stroke patients[J]. Sci Rep, 2024, 14(1): 3082. doi: 10.1038/s41598-024-53616-w [4] Rodríguez-Fernández A, Lobo-Prat J, Font-Llagunes J M. Systematic review on wearable lower-limb exoskeletons for gait training in neuromuscular impairments[J]. J NeuroEngineering Rehabil, 2021, 18(1): 22. doi: 10.1186/s12984-021-00815-5 [5] 孙阳阳, 张亚妮, 卢迎, 等. 机器人辅助步态训练联合常规训练对严重烧伤后下肢运动及平衡功能障碍患者影响的前瞻性随机对照研究[J]. 机器人外科学杂志(中英文), 2024, 5(5): 876-880+886. doi: 10.12180/j.issn.2096-7721.2024.05.021 [6] 中华医学会神经病学分会, 中华医学会神经病学分会脑血管病学组. 中国各类主要脑血管病诊断要点2019[J]. 中华神经科杂志, 2019, 52(9): 710-715. doi: 10.3760/cma.j.issn.1006?7876.2019.09.003 [7] Warner J J, Harrington R A, Sacco R L, et al. Guidelines for the early management of patients with acute ischemic stroke: 2019 update to the 2018 guidelines for the early management of acute ischemic stroke[J]. Stroke, 2019, 50(12): 3331-3332. doi: 10.1161/STROKEAHA.119.027708 [8] Hemphill J C, Greenberg S M, Anderson C S, et al. Guidelines for the management of spontaneous intracerebral hemorrhage: A guideline for healthcare professionals from the American heart association/American stroke association[J]. Stroke, 2015, 46(7): 2032-2060. doi: 10.1161/STR.0000000000000069 [9] 柏敏, 曹丽华, 叶子琦, 等. 肌电感知机器人辅助训练联合成对关联刺激对脑卒中偏瘫患者上肢功能的影响[J]. 中国康复理论与实践, 2025, 31(5): 505-512. doi: 10.3969/j.issn.1006-9771.2025.05.002 [10] Lattouf N A, Tomb R, Assi A, et al. Eccentric training effects for patients with post-stroke hemiparesis on strength and speed gait: A randomized controlled trial[J]. NeuroRehabilitation, 2021, 48(4): 513-522. doi: 10.3233/NRE-201601 [11] Bei N, Long D, Bei Z, et al. Effect of water exercise therapy on lower limb function rehabilitation in hemiplegic patients with the first stroke[J]. Altern Ther Health Med, 2023, 29(7): 429-433. [12] Rocha L S O, Gama G C B, Rocha R S B, et al. Constraint induced movement therapy increases functionality and quality of life after stroke[J]. J Stroke Cerebrovasc Dis, 2021, 30(6): 105774. doi: 10.1016/j.jstrokecerebrovasdis.2021.105774 [13] 李海霞, 祁香兴, 张祖善. 不同NIHSS评分的急性脑梗死病人Lp-PLA2、hs-CRP、D-D表达水平及其意义分析[J]. 中西医结合心脑血管病杂志, 2020, 18(11): 1804-1807. doi: 10.12102/ji.ssn.1672-1349.2020.11.034 [14] 高元杰, 钟纯正, 王御林, 等. 老年脑卒中患者睡眠结构异常与认知功能MMSE、MoCA评分的关系[J]. 中国老年学杂志, 2020, 40(16): 3570-3572. doi: 10.3969/j.issn.1005-9202.2020.16.063 [15] Alsubiheen A M, Choi W, Yu W, et al. The effect of task-oriented activities training on upper-limb function, daily activities, and quality of life in chronic stroke patients: A randomized controlled trial[J]. Int J Environ Res Public Health, 2022, 19(21): 14125. doi: 10.3390/ijerph192114125 [16] Marzolini S, Robertson A D, MacIntosh B J, et al. Effect of high-intensity interval training and moderate-intensity continuous training in people with poststroke gait dysfunction: A randomized clinical trial[J]. J Am Heart Assoc, 2023, 12(22): e031532. [17] Huang H, Su X, Zheng B, et al. Effect and optimal exercise prescription of robot-assisted gait training on lower extremity motor function in stroke patients: A network meta-analysis[J]. Neurol Sci, 2025, 46(3): 1151-1167. doi: 10.1007/s10072-024-07780-6 [18] 白耀琳, 罗文萍. 传统运动疗法在肺癌术后患者功能康复的运用[J]. 四川中医, 2023, 41(9): 57-59. doi: 10.3969/j.issn.1000-3649.2023.9.sczy202309016 [19] 金霞, 曹迎, 汪吴臻. 外骨骼康复机器人训练对亚急性脑卒中患者平衡和下肢功能的影响[J]. 中国康复, 2025, 40(5): 265-270. doi: 10.3870/zgkf.2025.05.002 [20] 陈飞锋, 汪翠, 陈丽娜. 中药熏蒸结合下肢康复机器人辅助步行训练治疗脊髓损伤后肌张力增高临床研究[J]. 新中医, 2022, 54(16): 89-94. doi: 10.13457/j.cnki.jncm.2022.16.020 [21] 李响, 张洪蕊, 杨帅, 等. 低频重复经颅磁刺激联合下肢康复机器人对脑卒中患者平衡和运动功能的影响[J]. 中国康复医学杂志, 2025, 40(2): 211-216. doi: 10.3969/j.issn.1001-1242.2025.02.007 [22] 安丹蔷, 季宇宣, 张瀚之, 等. 下肢康复训练机器人联合等速肌力训练对老年脑卒中偏瘫患者神经功能、步行能力、Lovett肌力分级及平衡能力的影响[J]. 临床和实验医学杂志, 2024, 23(4): 377-381. doi: 10.3969/j.issn.1671-4695.2024.04.011 [23] 杨玲玲, 刘津, 蔡华安. 下肢康复机器人在脑卒中步态康复中的应用进展[J]. 实用医院临床杂志, 2022, 19(2): 221-224. doi: 10.3760/cma.j.cn421666-20240604-00431 -
